form.h44

107800-600-E14

End module form.h44 for the flexible configuration of lighting structures,
for suspended mounting
, ,

Downloads
Technische Daten
Technik
Zubehör

Downloads

Technische Daten

  • Product description
    End module form.h44 for the flexible configuration of lighting structures,
    for suspended mounting
    Article number
    107800-600-E14
    Colour
    white
  • Lighting technology - LDT
    Control gear / connection
  • Housing / Material

    housing of extruded aluminium profile
    Dimensions and weights
    Weight: 4 kg length: 1400 mm width: 44 mm height: 44 mm Rotation range: Swivel range:
    Protection classes / test marks

    5 years Hoffmeister warranty
    Made in Germany     Maximum ambient temperature: Mark of conformity: manufactured according to DIN VDE 0711 / EN 60598

Technik

Optional accessoires

end cap
for form.h44 profiles

10783500910

mounting element
for pendant tube suspensions
for form.h44

10785000000

mounting element, Type 90°
fixing element for steel cable suspensions
for form.h44

10784100000

mounting element, Type 90°
fixing element for pendant tube suspensions
for form.h44

10785100000

pendent tube, with cable, 7-pole
for form.h44

10785700910

mounting element
fixing element for steel cable suspensions
for form.h44

10784000000

90° coupler
for mechanical connection of form.h44 profiles

10783100910

canopy, 2 x 7 x 2.5 mm²
with connection possibility
for form.h44

10784800910

supply cable, 5 x 0.75 mm²
for form.h44

10784500000

supply cable, 5 x 0.75 mm²
for form.h44

10784500910

supply cable, 7 x 0.75 mm²
for form.h44

10784700000

supply cable, 7 x 0.75 mm²
for form.h44

10784700910

pendent tube
for form.h44

10785800910

pendent tube, with cable, 5-pole
for form.h44

10785500910

canopy, 2 x 5 x 2.5 mm²
with connection possibility
for form.h44

10784900910

cover diffuse, L=1772mm
for form.h44

10782400927

cover diffuse, L=1172mm
for form.h44

10782200927

cover diffuse, L=1472mm
for form.h44

10782300927

Steelwire suspension, 2500 mm
for control.x tracks or other profile systems

09508900000
