complx

10874204910R

ceiling recessed luminaire complx.100 rim
LED COB 2000 lm, 4000 K, 14 W

Downloads
Technische Daten
Technik
Zubehör

Downloads

Technische Daten

  • Product description
    ceiling recessed luminaire complx.100 rim with a rim projecting over the ceiling
    for installation into suspended ceilings
    Article number
    10874204910R
    Colour
    white
  • Lighting technology - LDT
    with LED COB 2000 lm
    colour temperature: 4000 K
    colour rendering index (manually): CRI >90
    L90 / B10 (50.000h)
    SDCM < 2
    net luminous flux: 1260 lm
    total load: 14 W
    luminous efficacy: 90.0 lm/W     rotationsymmetrical light distribution, wide flood cut of angle: 40 °
    beam angle: 69 °
    UGR: 19
    Control gear / connection
    with external LED power unit, electronic, 220-240 V, 0/50/60 Hz
  • Housing / Material

    housing of die cast aluminium
    Dimensions and weights
    Weight: 0.86 kg height: 115 mm Rotation range: Swivel range:
    Protection classes / test marks
    protection rating: IP44
    protection class I
    5 years Hoffmeister warranty
    Made in Germany     Maximum ambient temperature: Mark of conformity: manufactured according to DIN VDE 0711 / EN 60598|CE

Technik

Optional accessoires

housing for concrete cast
for recessed downlights complx.100 rim

10860510000
